Uniview 5MP Bullet IP Camera with 2.7mm - 13.5mm Vari-Focal Motorized Lens (IPC2325SB-DZK-I0)
SKU
IPC2325SB-DZK-I0
- SKU: IPC2325SB-DZK-I0
- 5 MP Resolution
- Weather Protection: IP67
- Power Over Ethernet
- 3 Year Warranty
- SD Card Slot
- Human Body Detection
UNV Network vari-focal water-resistant IR bullet camera, 1/2.7" 5MP PS CMOS, Ultra 265/H.264/MJPEG, Human Body/Vehicle Detection features, max 30fps@5MP(2592x1944), 2.7-13.5mm motorized lens, IR Distance up to 164 feet, 120dB Optical WDR, 0.002Lux Starlight, Micro SD up to 128GB, Audio I/O, Alarm I/O, DC12V, PoE (up to 10W), IP67. Compatible with: TR-JB07-D-IN, TR-UP06-B-IN,TR-UP06-C-IN
| Is Discontinued | No |
|---|---|
| Color | White |
| Sensor Size | 1/2.7", progressive scan, CMOS |
| Resolution | 5 MP |
| Lens | 2.7 ~ 13.5mm, AF automatic focusing and motorized zoom lens |
| Detect | 60.8m (199.5ft)~303.8m (997ft) |
| Observe | 24.3m (79ft)~121.5m (398.5ft) |
| Recognize | 12.2m (40ft)~60.8m (199.5ft) |
| Identify | 6.1m (20ft)~30.4m (100ft) |
| Angle of View (H) | 107°~ 30° |
| Angle of View (V) | 57°~ 18° |
| Angle of View (O) | 111°~34° |
| Adjustment angle (Pan) | Pan: 3° ~ 357° |
| Adjustment angle (Tilt) | Tilt: 0° ~ 90° |
| Adjustment angle (Rotate) | Rotate: 0° ~ 360° |
| Shutter | Auto/Manual, shutter time: 1 ~ 1/100000s |
| Minimum Illumination | Colour: 0.002 Lux (F1.2, AGC ON) 0 Lux with IR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Digital Noise Reduction | 2D/3D DNR |
| S/N | >56dB |
| IR Range (or LED) | Up to 50m (164 ft) IR range |
| IR Wavelength | 850nm |
| IR On/Off Control | Auto/Manual |
| Defog | Digital Defog |
| Wide Dynamic Range | 120dB |
| Video Compression | H.264, H.265, MJPEG, Ultra 265 |
| H.264 code profile | Baseline profile, High profile, Main Profile |
| Frame Rate | Main Stream:5MP (2880*1620), Max 30fps; 4MP (2560*1440), Max 30fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 3 |
| Bit Rate (min~max) | 128 Kbps~16 Mbps |
| OSD | Up to 8 OSDs |
| Privacy Mask | Up to 4 areas |
| Region of Interest | Up to 8 areas |
| Motion Detection | Up to 4 areas |
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Smart IR (or Smart Illumination) | Supported |
| Image Flip | 180°, 90° Clockwise, 90° Counter Clockwise, Horizontal, Normal, Vertical |
| Dewarping | No |
| HLC | Yes |
| BLC | Yes |
| Audio Compression | G.711 |
| Audio Suppression | No |
| Audio Sampling Rate | 8KHZ |
| Edge Storage (SD) | Micro SD, Up to 256GB |
| Network Storage | ANR |
| Supported Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS |
| Compatible Integration | API, ONVIF Profile T |
| Compatible Clients | EZLive, EZStation, EZView |
| Web Browser Support | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
| Network Interface | 1 RJ45 10/100M Base-TX Ethernet |
| Built-in Mic | No |
| Certifications | CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 |
| Maximum Power Consumption | 8.0 W |
| Dimensions (Ø x H) | 245 × 86 × 72mm (9.6” × 3.4” × 2.8”) |
| Net Weight | 0.92kg (2.0lb) |
| Material | Metal |
| Operating Conditions | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Surge Protection | 6KV |
| Ingress Protection | IP67 |
| Special Features | Intelligent Target Detection |
| Focal Length | 2.7mm - 13.5mm |
| Illumination Type | Infrared |
| Resolution | 5MP |
